7-Blade HX35 vs 8-Blade HX40

Posted by NewTurboTuner, Jan 12, 2018

Please Support Fuel Injector Clinic
Please Support Morrison Fabrication
  1. NewTurboTuner

    NewTurboTuner Proven Member

    385
    19
    Joined Jul 21, 2006
    Rslv, Arkansas
    So if the 7-Blade HX35 flows 60lb/min, and the 8-Blade HX40 flows 60/min..... what are the pro’s and cons of the two turbos?

    Why would anyone use a 8-B HX40 if they could get a quicker spoiling HX35 that’d make the same power?


    854  6

    1991 Mitsubishi Eclipse GSX
    automatic · 2G DSM
    Loading...
  2. JusMX141

    JusMX141 Moderator

    12,761
    744
    Joined Dec 13, 2005
    Greensburg, Pennsylvania
    The part you're missing is the HX35 will only flow that much *in a suitable turbine housing*. Often this means the HX40 will either spool near the same or possibly even quicker if it's being used in a small a/r turbine housing where the HX35 in the same size housing would be severely limited; of course that small housing is also going to hurt the HX40's ability to make big horsepower as well.

    The common 8-blade HX35 compressor is 56/83mm and the common 8-blade HX40 compressor is 58/83mm...the 7-blade HX35 wheel is smaller at 54/78mm but is a revised design that is more-aerodynamic in addition to being lighter and allowing higher shaft speeds to be achieved.

    So if you're using a DSM-flanged housing with a 60 lb/min goal go for the HX40 for sure as I don't think any HX35 in the .55 housing has made beyond the mid-50's. If you're using a T3 housing and would prefer something quick-spooling, forget both and use the HY35 which is a 54/78mm HX35 compressor on a 65/58mm HX30 turbine and was found on 99-02 Dodge trucks with an automatic transmission. The HY35 will have a straight outlet on the compressor cover just like the HX35....not to be confused with the HE341 from 03-04 Dodge trucks that has a 90* bend on the compressor outlet.


    2K  0

    1998 Mitsubishi Eclipse GST
    manual · 2G DSM

    5K  14

    1997 Mitsubishi Eclipse GSX
    awd · manual · 2G DSM

    2K  0

    1992 Eagle Talon TSi
    manual · 1G DSM

    3K  0

    1993 Eagle Talon TSi AWD
    manual · 1G DSM
    Loading...
  3. NewTurboTuner

    NewTurboTuner Proven Member

    385
    19
    Joined Jul 21, 2006
    Rslv, Arkansas
    I should have specified which turbine housing, in my mind I don’t think about the smaller DSM housing for them. I think more along the lines of the Open-T3 Bep housing or the stock 12cm^2 HX35, & 16cm^2 HX40, because I want them to be able to run up to their full potential.

    I’m in the process of deciding what Holset I want to go with. Over the years I’ve tried many very different turbos 14b, 16g, 20g, gtx2867r, FP3065, FP88HTZ. I like the idea of a budget friendly, robust, reliable turbo in the 500-600+whp range (e85).

    I have trouble deciding if I could live with a 7-blade hx35 (reading as they flow around 60lb/min, same as 8-blade hx40). Or skip up to the super 7 & 6 Blade hx40.

    I just wonder if I should skip over the idea of a 8-blade hx40, if it’s possible the 7-blade hx35 will give me the same flow but better spool too?


    854  6

    1991 Mitsubishi Eclipse GSX
    automatic · 2G DSM
    Loading...
  4. NewTurboTuner

    NewTurboTuner Proven Member

    385
    19
    Joined Jul 21, 2006
    Rslv, Arkansas
    Other Holset turbos interest me aswell but I don’t see as much info on them and am worried I may get something I don’t want. What is the HY35’s max lb/min flow?

    What about other hx37 type variants?

    This all being discussed in the context of Open-T3 &/or T3^2 exhaust housings.


    854  6

    1991 Mitsubishi Eclipse GSX
    automatic · 2G DSM
    Loading...
  5. bastarddsm

    bastarddsm Proven Member

    4,436
    1,006
    Joined Aug 26, 2003
    Mendota, Illinois
    I don't think youv'e searched much. There is extensive information on virtually every holset turbo ever on this site.


    Showcar Build 5K  1

    1991 Eagle Talon N/T
    9.805 @ 144.00 · 1G DSM
    Loading...
    JusMX141 likes this.
  6. NewTurboTuner

    NewTurboTuner Proven Member

    385
    19
    Joined Jul 21, 2006
    Rslv, Arkansas
    Bastarddsm I’ve spent hours upon hours reading through Tuners over the the last 11+Years I’ve been here. Searching and reading dosent always get you want you want to know. I’ve read enough past holset posts to know you had horrible taste for divided manifold setups how bought that LOL.

    On the “Holset FAQ” thread in the discription of HY35 it still says it’s potential is untested. Maybe someone has tried it by now but I didn’t see where. How bought you contribute to the post instead of waste of your time with the age old “search”. Anyways the HY probably isn’t for me cause I’m more focused on more pwr, vs faster spool. I was just curious enough to ask it’s max flow that’s all


    854  6

    1991 Mitsubishi Eclipse GSX
    automatic · 2G DSM
    Loading...
    iugrad92turbo likes this.
  7. slowwhite

    slowwhite Proven Member

    216
    90
    Joined Oct 27, 2013
    camden, South Carolina
    This is probably irrelevant but I ran both the 7 blade hx35 and the 7 blade hx40 in the .55 bep housings.

    As far as spool goes, logged 400rpms difference.

    Lbs/min:
    50-53lbs/min - hx35
    54-56lbs/min - hx40

    And honestly I thought the hx35 was a lot more fun of a turbo for a street car doesn't seem like much but the 400rpms..
    Was noticeable especially since I didn't change my Rev limit I kept it at the 8,000rpms for both.


    Road Race Build 767  17

    1997 Mitsubishi Eclipse GSX
    awd · manual · 2G DSM

    Road Race Build 6K  25

    1997 Mitsubishi Eclipse GSX
    425 whp · 354 lb/ft · 2G DSM
    Loading...
  8. NewTurboTuner

    NewTurboTuner Proven Member

    385
    19
    Joined Jul 21, 2006
    Rslv, Arkansas
    slowwhite yes that does help. Even though it’s not 7bHX35 vs 8bHX40 gives good account of the spool differences. Although with the smaller .55 housing the spool maybe closer together, than larger T3 options.

    If both the 7-Blade HX35, & 8-Blade HX40 flow at a similar 60lb/min (except HX40 has noticeably more lag), then it may not be any reason to run a HX40, unless it’s a 7 or 6 Blade HX40 that can flow closer to 70lb/min.

    This is what I’m seeing and wondering about. Helps to more finely narrow the choices down between spool or top end power.


    854  6

    1991 Mitsubishi Eclipse GSX
    automatic · 2G DSM
    Loading...
  9. Vegas smith

    Vegas smith Proven Member

    2,756
    1,312
    Joined Dec 2, 2002
    Houston, Texas

    Street Build 3K  10

    1993 Eagle Talon TSi AWD
    awd · manual · 1G DSM
    Loading...
    Dstarperformance01 likes this.
  10. iugrad92turbo

    iugrad92turbo Proven Member

    10,455
    382
    Joined May 22, 2007
    Kalamazoo, Michigan
    I am too running a hx40 too in the bep. Housing not t3 yet gonna see what she does.


    6K  4

    1992 Eagle Talon TSi
    awd · manual · 1G DSM
    Loading...
  11. MorrisonFab

    MorrisonFab Supporting Vendor

    124
    390
    Joined May 28, 2017
    Johnson Creek, Wisconsin
    To the original post, I think the larger turbine wheel would be the the main difference, not just the compressor wheel specs. It would seem that even if the HX40 were to make the same power, you wouldn't have to lean on it as hard.

    From where the thread is going, I'm not sure if the HY35 could be considered "untested" or "unproven" at this point. It's been in the 600whp range more than once and trapped around the 140's. It sounds like exactly what you are looking for, really.
    If spool is a concern, and divided is out of the question, the manifold it's mated to should be looked at. Specifically small runner, which is efficiently matched to the power range of those turbos (HY35 or HX35 in the T3 open housing, and open T3 HX40).

    Cheers!


    Street Build 1K  20

    1992 Eagle Talon TSi AWD
    awd · manual · 1G DSM

    Street Build 2K  18

    1993 Eagle Talon TSi AWD
    868 whp · 546 lb/ft · 1G DSM
    Loading...
    NewTurboTuner and iugrad92turbo like this.
  12. 1990TSIAWDTALON

    1990TSIAWDTALON Moderator

    4,550
    1,981
    Joined Nov 14, 2013
    Independence, Kansas
    The 8 blade Holset HX40 comes in sooner and has a smoother transistion to high boost. The 7 blade HX40 is 5-600 rpms later than the 8 blade but hits much HARDER. I can report later on the difference compaired to a Super 6 when the ole girl is back up and running later this year with new mods. :sneaky:


    Street Build 3K  27

    1992 Eagle Talon TSi AWD
    awd · automatic · 1G DSM

    510  14

    1990 Mitsubishi Eclipse GSX
    awd · manual · 1G DSM

    440  18

    1967 Chevrolet Camaro RS
    rwd · automatic · Misc Vehicles

    Street Build 642  4

    1998 Eagle Talon TSi
    fwd · manual · 2G DSM

    Street Build 5K  11  25

    1990 Eagle Talon TSi AWD
    13.620 @ 108.460 · 1G DSM
    Loading...
  13. OH91awd

    OH91awd Proven Member

    642
    284
    Joined Sep 22, 2011
    chillicothe, Ohio
    I wish I had a log on this computer to show how my 8 blade hx40 spooled on a .70 ar t3 housing. I want to say car was at full boost on wastegate (26psi as logged in link) by 4400rpm. my car went 10.89 but I was having fuel pump issues as well so I think it should've went faster.


    Drag Race Build 2K  17

    1992 Eagle Talon TSi AWD
    10.89 @ 125.67 · 1G DSM
    Loading...
  14. 1990TSIAWDTALON

    1990TSIAWDTALON Moderator

    4,550
    1,981
    Joined Nov 14, 2013
    Independence, Kansas
    That sounds about right for my 8 blade also. The difference was the strength of the motor when boost came in with the 7.


    Street Build 3K  27

    1992 Eagle Talon TSi AWD
    awd · automatic · 1G DSM

    510  14

    1990 Mitsubishi Eclipse GSX
    awd · manual · 1G DSM

    440  18

    1967 Chevrolet Camaro RS
    rwd · automatic · Misc Vehicles

    Street Build 642  4

    1998 Eagle Talon TSi
    fwd · manual · 2G DSM

    Street Build 5K  11  25

    1990 Eagle Talon TSi AWD
    13.620 @ 108.460 · 1G DSM
    Loading...
    NewTurboTuner likes this.
  15. OH91awd

    OH91awd Proven Member

    642
    284
    Joined Sep 22, 2011
    chillicothe, Ohio
    ive contemplated swapping wheels in this but I also wanna see where this thing will take me as well on about 38psi.


    Drag Race Build 2K  17

    1992 Eagle Talon TSi AWD
    10.89 @ 125.67 · 1G DSM
    Loading...
  16. iugrad92turbo

    iugrad92turbo Proven Member

    10,455
    382
    Joined May 22, 2007
    Kalamazoo, Michigan
    Just looked at my turbo its a 8 blade hx40 in
    55 bep. But want to see what she will do on the .70 ar, with the twin scrolls set up. Plan on getting her running soon.


    6K  4

    1992 Eagle Talon TSi
    awd · manual · 1G DSM
    Loading...
  17. iceguru1114

    iceguru1114 Proven Member

    137
    199
    Joined Nov 24, 2014
    Atlanta, Georgia
    I think this is the info you're looking for: the HY35 on my truck sounds awesome!!


    Autocross Build 3K  15

    1992 Mitsubishi Galant VR-4
    awd · manual · Galant VR-4
    Loading...
    iugrad92turbo likes this.
  18. joemamma

    joemamma Proven Member

    281
    45
    Joined Jan 26, 2017
    williston, North Dakota
    good info


    Drag Race Build 1K  1

    1998 Mitsubishi Eclipse GSX
    awd · automatic · 2G DSM

    Drag Race Build 101  1

    1997 Mitsubishi Eclipse GSX
    awd · automatic · 2G DSM

    Street Build 874  2

    1994 Eagle Talon TSi AWD
    manual · 1G DSM
    Loading...
  19. NewTurboTuner

    NewTurboTuner Proven Member

    385
    19
    Joined Jul 21, 2006
    Rslv, Arkansas
    That’s good feedback on the 8 vs 7 Blade HX40. Seems I’ve read that less blades have better high Boost efficiency, and more blades have better low boost efficiency; makes sense.


    854  6

    1991 Mitsubishi Eclipse GSX
    automatic · 2G DSM
    Loading...
  20. NewTurboTuner

    NewTurboTuner Proven Member

    385
    19
    Joined Jul 21, 2006
    Rslv, Arkansas
    All good feedback guys thanks. I ask because I’d like higher HP for a street/strip Drag-Grudge race car. But also my heart loves a hard hitting turbo, which is more fun on the street. I know I wouldn’t be unhappy with a HX35, but the car is targeting drag race so I need the top end too.

    I already have a manifold bought for my setup.
    It’s one of the old Punishment Racing T3^2 manifolds, 1.5” runners (schedual 40 I’ve heard). Im considering either 12cm^2 HX35, or 16cm^2 HX40.

    The KICKER is..... mine is a Auto car. So Ive gotta buy a converter and turbo that match. Makes my desicion more complicated. But maybe that also means i don’t have to worry about spool as much if I go higher stall. Idk it’s my 1st Auto DSM so all new to me (part of the fun though).

    Last edited: Jan 13, 2018

    854  6

    1991 Mitsubishi Eclipse GSX
    automatic · 2G DSM
    Loading...
    iugrad92turbo likes this.
  21. bastarddsm

    bastarddsm Proven Member

    4,436
    1,006
    Joined Aug 26, 2003
    Mendota, Illinois
    I've posted a lot on the he351 and the hy35 over the years. Not sure how you could miss it in the searches.


    Showcar Build 5K  1

    1991 Eagle Talon N/T
    9.805 @ 144.00 · 1G DSM
    Loading...
  22. NewTurboTuner

    NewTurboTuner Proven Member

    385
    19
    Joined Jul 21, 2006
    Rslv, Arkansas
    I’ve never considered the he351 or HY35 before so never searches them nor is this thread about them. Go troll some other thread if you have nothing constructive to add


    854  6

    1991 Mitsubishi Eclipse GSX
    automatic · 2G DSM
    Loading...
  23. iugrad92turbo

    iugrad92turbo Proven Member

    10,455
    382
    Joined May 22, 2007
    Kalamazoo, Michigan
    I' running a hx40 8 blade in a .55 housing, waiting to see how she does, it' a street car, but do have the t3 on my list if upgrades going , for low end torque not a high horsepower car.


    6K  4

    1992 Eagle Talon TSi
    awd · manual · 1G DSM
    Loading...
  24. Vegas smith

    Vegas smith Proven Member

    2,756
    1,312
    Joined Dec 2, 2002
    Houston, Texas
    You might want to contact @MorrisonFab and @beansblacktsi as they both have auto twinscroll hx35s and hx40s respectively.


    Street Build 3K  10

    1993 Eagle Talon TSi AWD
    awd · manual · 1G DSM
    Loading...
    NewTurboTuner and iugrad92turbo like this.
  25. iugrad92turbo

    iugrad92turbo Proven Member

    10,455
    382
    Joined May 22, 2007
    Kalamazoo, Michigan
    Yes they have some great pieces.


    6K  4

    1992 Eagle Talon TSi
    awd · manual · 1G DSM
    Loading...
