97 GSX Build

mattasi

Proven Member
841
5
Feb 22, 2008
Springfield, Oregon
First things first, a little history. I bought my first eclipse when i turned 16. I worked a paper route to save up for it. I am now 25 and on my fifth DSM. I am very deticated to these cars, and driving any other car would just not be the same. I continue to learn new things about DSM's everyday thanks to dsmtuners.com. I am starting this blog basically, for the DSM community, and to help keep track of my progress. Oh and of course to read your comments. I currently have a Silver 97 GSX with a fully built 6bolt longblock motor pushed by an old school FP green turbo on ECM link v3. It made 389hp tuned by Lucas @ English Racing in washington. On 8-25-2011 my motor spun a rod bearing , so I am pulling the motor out and the complete build begins....haha...And by complete build, i am talking about a new English racing zero mile 6 bolt motor longblock, with built head, new stage 4 Sheppard transmission, new ACT 2600lb sprung 6-puck clutch kit, new OEM master/slave cylinders ect, repaint engine bay stock silver, and all other parts cleaned/painted or replaced by new parts. New steering rack, tie rod ends, end links, knuckel kits, upper and lower control arms, sway bar bushings. Turbo rebuild. Power steering pump rebuild. A/C delete. Prep Intake manifold for SD bundle kit. Install Inovative MTX-L wideband I just got in the mail. After everything is back together and working, it will be going to English Racing for a SD tune I currently have the stock maf.

Picture of the beauty before tearing it down...
You must be logged in to view this image or video.


I started out by removing the oil pan to take a look at things and found this.
You must be logged in to view this image or video.


Here is some of the bearing material in the bottom of the oil pan.
You must be logged in to view this image or video.


Valve cover and air intake/intercooler pipes removed.
You must be logged in to view this image or video.


Me wondering what I am getting myself into haha...
You must be logged in to view this image or video.


Almost ready to remove the motor.
You must be logged in to view this image or video.


Engine Hoist ready to go.
You must be logged in to view this image or video.


Here we go.
You must be logged in to view this image or video.


Almost there, hope the chain doesn't break LOL..
You must be logged in to view this image or video.


Another view.
You must be logged in to view this image or video.


You must be logged in to view this image or video.


Transmission is off.


You must be logged in to view this image or video.


Ready to drive the motor to Engish Racing about 3 hours away from me.
You must be logged in to view this image or video.

Last edited:

mattasi

Proven Member
841
5
Feb 22, 2008
Springfield, Oregon
Turbo rebuild kit came in from Kamak Dynamics.
You must be logged in to view this image or video.


You must be logged in to view this image or video.


You must be logged in to view this image or video.


You must be logged in to view this image or video.


Old Parts
You must be logged in to view this image or video.


Done!
You must be logged in to view this image or video.


mattasi

Proven Member
841
5
Feb 22, 2008
Springfield, Oregon
This is the engine bay just after the motor was removed.
You must be logged in to view this image or video.


Started to unclip the wire harness from the body.
You must be logged in to view this image or video.


Removed everything from the wheel wells.
You must be logged in to view this image or video.


Removing the front subframe.
You must be logged in to view this image or video.


Degressing.
You must be logged in to view this image or video.


Not that it matters because it will all come apart anyways, but I got the whole clutch line/assembly out in one piece. :p
You must be logged in to view this image or video.


Sanding out defects.
You must be logged in to view this image or video.


Etch primer on the bare metal spots. And then spot primer over the etch primer.
You must be logged in to view this image or video.


Etch primer and spot primer sanded and ready for high build primer.
You must be logged in to view this image or video.


Outside the paint booth.. LOL...
You must be logged in to view this image or video.


Primer coat#1 (I did two coats)
You must be logged in to view this image or video.


Underside of hood before picture.
You must be logged in to view this image or video.


Hood after etch primer.
You must be logged in to view this image or video.


You must be logged in to view this image or video.


Painted stock silver!
You must be logged in to view this image or video.


You must be logged in to view this image or video.


You must be logged in to view this image or video.


You must be logged in to view this image or video.


You must be logged in to view this image or video.

Last edited:

GsXdSmKingGsX

Proven Member
4,582
31
Dec 13, 2008
Plainview, Minnesota
Badass.. I'm doing practically the same build on an identical car other than mine is a 7bolt still. Good luck with the build amigo.


mattasi

Proven Member
841
5
Feb 22, 2008
Springfield, Oregon
I took the small three hour drive and went and picked up the motor. Very happy so far.

What I had done to it, 6 bolt longblock, build by English Racing / Wiseco HD 1400 Forged Pistons 9:1 compression / Eagle H-Beam Rods / ARP Head Studs / OEM Crank / ACL Race Bearings / Head upgraded with GSC valve springs, TI retainers, Chromoly seats, Supertech valves with the 4-angle intake valve grind and the 4-angle radius exhaust valve grind / HKS 272 intake and exhaust cams / HKS adjustable cam gears / Cosmetic hg /
:)

It's coming along, pics below. Oh and the crate it is sitting on, I custom made for this engine to fit into perfectly. I needed a way to strap it into my truck. I doesn't look like much but it is very functional and strong.
You must be logged in to view this image or video.


You must be logged in to view this image or video.


mattasi

Proven Member
841
5
Feb 22, 2008
Springfield, Oregon
Got my Sheppard Stage-4 transmission in yesterday. Everything looks great, I can't wait to try this thing out! I got the stage-4 build, but I had them use a 4-spider center diff instead of welded for better street use, since this is a street car. I had the EVOIII 1st and 5th gear sets installed. The EVOIII 1st is 11% taller than stock and will let me go 45mph instead of the stock gear that is maxed at 39mph. The taller 1st gear is stronger, allows you to get off the line better for drag racing, and is also more useful in short track or auto x racing and makes it more feasible to shift to 1st for the slower corners. The EVOIII 5th gear provides a quieter ride and saves gas. At 55 MPH, the stock ratio has you at about 2500 RPM, where the taller 5th has you closer to 2000!

You must be logged in to view this image or video.


You must be logged in to view this image or video.


You must be logged in to view this image or video.


I got the main order from JNZ in a few days ago, can you scope some of the goodies in the pic below?
You must be logged in to view this image or video.

Last edited by a moderator:

mattasi

Proven Member
841
5
Feb 22, 2008
Springfield, Oregon
Gaskets,gaskets,and more gaskets.

gaskets aren't goodies :), How bout the fluidamper, or the inovative mtx-l wideband :hellyeah:

How much did the suspension arms set u back?

I got knuckle kits for both sides from Extreme psi, it includes the knuckle and both lower arms, $109 each side.
Then the upper arms came from JNZ at $107 each so around $400 for all the suspension arms....

Awesome. How much was the Stage 4 Shep and the Evo III gears.?????

The build I had done, including shipping both ways, came to $3010


mattasi

Proven Member
841
5
Feb 22, 2008
Springfield, Oregon
hey man just a quick question.. how much did it cost you to have the engine sent in and built completly like you did? My guess is around $1500?

Closer to $5k...I dropped it off and picked it up.

After getting all of these new parts in, I have been just cleaning/painting other parts like the front subframe, windshied wiper assembly, motor mounts, break/clutch lines and small brackets ect.... I am buying new zinc plated bolts as I put things back together. If I can't find the bolt I want then I buy the OEM bolt from Mitsubishi. I try to do something on the car everyday, even if it's small so that progress doesn't stop till i'm done with this build. Here is a short video of removing the front subframe bushings. After I get the front subframe done with new bushings and paint I will be moving onto putting the breaks lines back on.

MVI_1746.AVI - YouTube


mattasi

Proven Member
841
5
Feb 22, 2008
Springfield, Oregon
This weekend I finished sanding and painting the front subframe. I am doing all the misc parts in flat black, like break lines, brackets ect...

Cutting out the metal rings from the burnt out bushings.
You must be logged in to view this image or video.


Misc flat black parts.( see the motor mount in silver? I think it turned out nice LOL
You must be logged in to view this image or video.


Painted the front subframe frame flat black, now I need to press the new bushings in.
You must be logged in to view this image or video.


After the bushings are installed I will move onto putting the break lines back onto the car.


mattasi

Proven Member
841
5
Feb 22, 2008
Springfield, Oregon
Thanks for the encouragement and nice comments. I tried to install the subframe bushings last night with no luck, bent my c-clamp. And installing them with a rubber hammer is a joke. My friend happened to stop by last night when trying to install them and so he is going to help me out, by making me an aluminum tool to help press the rubber bushings in without damaging them. So hopefully they will be installed tonight so I can move on to other things. So last night I went ahead and installed the wiper assembly, painted, you guessed it flat black. New bolts and fender washers of course :cool:

You must be logged in to view this image or video.
