1G AC fuse box connectors

[willyp42]

Hey everyone,
Does anyone know what style of connectors are on the AC fuse box?
Some jerk put a AFPR where it’s supposed to be and I’d like to make a patch cable to relocate the fuse box when I go to add it back the summer.

Thanks.

You must be logged in to view this image or video.



[92AWDHX40]

Those go to the kick panel fuse, near the drivers side two connectors look for them.



[willyp42]

Those go to the kick panel fuse, near the drivers side two connectors look for them.

Hi,
I Can see where the connectors are in the engine bay,
but what I am trying to figure out is the style of connector so I can get a female / male set and make a patch cable to relocate.

hope that helps



[92AWDHX40]

Oh no idea check out ohm racing or sheridan m



[19Eclipse90]

For the large one: The 1990 Engine Compartment Hardness - A22

Nothing immediately comes to mind for the small one.



[Drewpy Dawg]

They’re a Sumitomo 250 series connector, IIRC. I’d have to double check the one on my car later.



[19Eclipse90]

This appears to be very close to the smaller one: DJ7061-2.3-11/21



[Drewpy Dawg]

6240-5160, 7283-1060 - Yazaki | 090IIU-6S-1 - Corsa Technic | 6-Way Kit

Motorsport electrical products: OEM and hard to find terminals and connector kits, wiring, harness supplies, tooling, and sensors for modern and vintage motorcycle, automotive applications. Easy online shopping, low cost shipping options, to expedited around the world. We accept Paypal and...

www.corsa-technic.com



[19Eclipse90]

Guess that means this would be the mate: https://www.corsa-technic.com/item.php?item_id=1359



[brads]

That smaller 6 pin looks a little bit more like this one:

7122-1360 - Sumitomo | MTU.IL-6P - Corsa Technic | 6-Way Kit

Motorsport electrical products: OEM and hard to find terminals and connector kits, wiring, harness supplies, tooling, and sensors for modern and vintage motorcycle, automotive applications. Easy online shopping, low cost shipping options, to expedited around the world. We accept Paypal and...

www.corsa-technic.com

So the mate might be:

6244-5061, 7123-1360 - Sumitomo | MTU.IL-6S - Corsa Technic | 6-Way Kit

Motorsport electrical products: OEM and hard to find terminals and connector kits, wiring, harness supplies, tooling, and sensors for modern and vintage motorcycle, automotive applications. Easy online shopping, low cost shipping options, to expedited around the world. We accept Paypal and...

www.corsa-technic.com

The above are Yazaki MT 090 unsealed series. The ones posted earlier are the TS 090 unsealed series

I ran into these similar ones before when tracking down the diagnostics connector for the 1Gs. I think the parts are compatible, but it has been years since I looked at it, so I could be wrong on that. Corsa Technic would probably know, they are good to work with.



[92AWDHX40]

Thanks for that link above for parts.



[willyp42]

That smaller 6 pin looks a little bit more like this one:

7122-1360 - Sumitomo | MTU.IL-6P - Corsa Technic | 6-Way Kit

Motorsport electrical products: OEM and hard to find terminals and connector kits, wiring, harness supplies, tooling, and sensors for modern and vintage motorcycle, automotive applications. Easy online shopping, low cost shipping options, to expedited around the world. We accept Paypal and...

www.corsa-technic.com

So the mate might be:

6244-5061, 7123-1360 - Sumitomo | MTU.IL-6S - Corsa Technic | 6-Way Kit

Motorsport electrical products: OEM and hard to find terminals and connector kits, wiring, harness supplies, tooling, and sensors for modern and vintage motorcycle, automotive applications. Easy online shopping, low cost shipping options, to expedited around the world. We accept Paypal and...

www.corsa-technic.com

The above are Yazaki MT 090 unsealed series. The ones posted earlier are the TS 090 unsealed series

I ran into these similar ones before when tracking down the diagnostics connector for the 1Gs. I think the parts are compatible, but it has been years since I looked at it, so I could be wrong on that. Corsa Technic would probably know, they are good to work with.

wow thanks for the great link and help everyone.
really appreciate this!
