What did my 4g63 come out of?

[Ahoffman1997]

I recently have purchased my first DSM and for the life of me I cannot find out what sort of or what this engine came out of. Vin on the block and transmission is KF5M3325PZTVR0647 the car is a 1998 Eclipse GST. Any help is much appreciated!



[motomattx]

Check the end of the cylinder head above the thermostat housing, it should be stamped, G6K - 4 or G6K -5 code for an evo 3 head.

if it is an evo 3 engine i would wonder why the previous owner took all the evo 3 bits off of it, I see mostly stock 2g components on it, I guess they could have parted it out and people were buying the jdm evo goodies, then he put stock 2g bits on it to sell it... There also is the possibility that the engine was replaced under warranty by Mitsubishi, they have no vins on the oem replacement blocks.

I bought this head years ago off of a guy on the internet G6k-2 = Evo1.

You must be logged in to view this image or video.



[mitsubishikid]

I bought this head years ago off of a guy on the internet G6k-2 = Evo1.

You must be logged in to view this image or video.

Yeah i got lucky and found a g6k-3 evo 2 head on a car that had other jdm bits on it.

You must be logged in to view this image or video.



[motomattx]

Yeah i got lucky and found a g6k-3 evo 2 head on a car that had other jdm bits on it.

You must be logged in to view this image or video.

Does yours have the same size studs in all exhaust ports like mine? I didn't know that there were only 5000 Evo1 made.



[Ahoffman1997]

Check the end of the cylinder head above the thermostat housing, it should be stamped, G6K - 4 or G6K -5 code for an evo 3 head.

if it is an evo 3 engine i would wonder why the previous owner took all the evo 3 bits off of it, I see mostly stock 2g components on it, I guess they could have parted it out and people were buying the jdm evo goodies, then he put stock 2g bits on it to sell it... There also is the possibility that the engine was replaced under warranty by Mitsubishi, they have no vins on the oem replacement blocks.

G6S 2 is what I have on my cylinder head

G6S 2 is what I have on my cylinder head

Also took these pics of turbo

You must be logged in to view this image or video.

You must be logged in to view this image or video.



[motomattx]

Also took these pics of turbo

You must be logged in to view this image or video.

You must be logged in to view this image or video.

Sounds like an Evo1 head, that turbo does not look like my Evo3 turbo at all, I'm not sure what the other Evo turbo's look like, although that looks newer to me.



[Ahoffman1997]

Sounds like an Evo1 head, that turbo does not look like my Evo3 turbo at all, I'm not sure what the other Evo turbo's look like, although that looks newer to me.

A guy from 1g2g eclipse group on Facebook seems to think it’s off a RVR



[motomattx]

A guy from 1g2g eclipse group on Facebook seems to think it’s off a RVR

Post number 9:

4g63 heads

Does anyone know how i might be able to tell what the head is that is fitted to my engine ?Over the past few weeks i had my car in the workshop to get some bigger valves and some port work, and they said they put another head on the car because mine looked like it had been shaved a few times and...

www.4gtuner.com

I would sooner trust these guys that have done research on the subject over some random person on Facebook.



[mitsubishikid]

Does yours have the same size studs in all exhaust ports like mine? I didn't know that there were only 5000 Evo1 made.

Mine has two m10 studs on the outside and evo 1-3 all list to use the larger m10 outside bolts according to megazip, but maybe different evo 1 models used all m8 exhaust fasteners like the rs etc. Do we have a post documenting head ID numbers on tuners? i have a few that id be willing to share/document the info on, i mean i know theres a ton of identify my cylinder head posts on here, but no dedicated post, that i have found as of yet bogussvo, made some great posts like camshafts etc, would love to see a cylinder head identification post made in the same format, solely for head pictures and id numbers refferenced with year make and model etc.



[1990TSIAWDTALON]

Put a borescope down a sparkplug hole and get a look at the top of the piston for any #'s for identification.
