2G Weird sound coming from under intake manifold

Posted by Ivan Garcia, Apr 3, 2019

Please Support STM Tuned
Please Support ExtremePSI
  1. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    Hi y’all! First time poster. I have a 97’ GST making a WAP WAP sound under the intake manifold when only in drive. Sometimes goes away with RPM. No power is lost just sounds pretty bad. Any idea what it could be?


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  2. Vegas smith

    Vegas smith Proven Member

    3,061
    1,608
    Joined Dec 2, 2002
    Houston, Texas
    No idea what wap equates to in sound. How can you tell it's coming from under the manifold when you drive?


    Street Build 4K  10

    1993 Eagle Talon TSi AWD
    awd · manual · 1G DSM
    Loading...
  3. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    We had it up on jack stands. It doesn’t really sound like metal hitting metal.


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  4. TK's9d2TSi

    TK's9d2TSi Supporting Member

    2,870
    1,060
    Joined Sep 11, 2017
    Cincinnati, Ohio
    WAP WAP WAP WAP WAP = launch control to me. :D Put up a video.


    350  3

    2000 Jeep Cherokee Sport - Classic
    awd · automatic · Misc Vehicles

    373  4

    93 Civic 4 Door -sold-
    fwd · manual · Misc Vehicles

    Street Build 3K  6

    1992 Eagle Talon TSi AWD
    12.625 @ 111.42 · 1G DSM
    Loading...
  5. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    I’ll try to put one up as soon as possible


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  6. ThunderChild

    ThunderChild Supporting VIP

    2,881
    963
    Joined Jan 5, 2012
    Rathdrum, Idaho
    Sounds like something might be wrapped around the CV axle


    Street Build 614  3

    1990 Plymouth Laser N/T
    fwd · manual · 1G DSM

    637  8

    1987 Toyota Pickup/Hilux
    awd · manual · Misc Vehicles

    Street Build 1K  7

    1997 Mitsubishi Eclipse Spyder GST
    fwd · manual · 2G DSM

    2K  0

    1992 Eagle Talon TSi AWD
    manual · 1G DSM

    Street Build 3K  10

    1992 Eagle Talon TSi AWD
    awd · manual · 1G DSM
    Loading...
  7. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    It happens when I’m parked in drive also, I’m leaning towards something transmission wise.


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  8. ThunderChild

    ThunderChild Supporting VIP

    2,881
    963
    Joined Jan 5, 2012
    Rathdrum, Idaho
    Does it increase with engine speed?
    It does seem like it will be trans related by your description, just cant think of anything that would produce a "wap wap wap" sound.


    Street Build 614  3

    1990 Plymouth Laser N/T
    fwd · manual · 1G DSM

    637  8

    1987 Toyota Pickup/Hilux
    awd · manual · Misc Vehicles

    Street Build 1K  7

    1997 Mitsubishi Eclipse Spyder GST
    fwd · manual · 2G DSM

    2K  0

    1992 Eagle Talon TSi AWD
    manual · 1G DSM

    Street Build 3K  10

    1992 Eagle Talon TSi AWD
    awd · manual · 1G DSM
    Loading...
  9. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    It’s not very constant either, sometimes it happens


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  10. ThunderChild

    ThunderChild Supporting VIP

    2,881
    963
    Joined Jan 5, 2012
    Rathdrum, Idaho
    Almost makes me think clutch or TOB related.


    Street Build 614  3

    1990 Plymouth Laser N/T
    fwd · manual · 1G DSM

    637  8

    1987 Toyota Pickup/Hilux
    awd · manual · Misc Vehicles

    Street Build 1K  7

    1997 Mitsubishi Eclipse Spyder GST
    fwd · manual · 2G DSM

    2K  0

    1992 Eagle Talon TSi AWD
    manual · 1G DSM

    Street Build 3K  10

    1992 Eagle Talon TSi AWD
    awd · manual · 1G DSM
    Loading...
  11. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    The vid I took says it’s too long


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  12. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California

    There we go


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  13. ThunderChild

    ThunderChild Supporting VIP

    2,881
    963
    Joined Jan 5, 2012
    Rathdrum, Idaho
    You're missing a tq converter bolt, im thinking you have others that are loose and hitting stuff. Either that or the flexplate is broken/cracked. Gonna need a bore scope to see, remove the transmission is pretty much a necessity to be sure.

    Your trans also seems to be flexing away from the block when you put it in drive (as well as the engine moving ALOT) which makes me think you've got loose or missing Bell housing bolts.

    Check the Bell housing bolts, replace any that are missing, tighten any loose ones. Do the same to the torque converter/flexplate bolts, and you may want to look into replacing uour motor mounts with at least new oem style, if not prothane inserts.


    Street Build 614  3

    1990 Plymouth Laser N/T
    fwd · manual · 1G DSM

    637  8

    1987 Toyota Pickup/Hilux
    awd · manual · Misc Vehicles

    Street Build 1K  7

    1997 Mitsubishi Eclipse Spyder GST
    fwd · manual · 2G DSM

    2K  0

    1992 Eagle Talon TSi AWD
    manual · 1G DSM

    Street Build 3K  10

    1992 Eagle Talon TSi AWD
    awd · manual · 1G DSM
    Loading...
  14. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    I just ordered a new one after I saw LOL


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  15. 007jimmy

    007jimmy Proven Member

    1,472
    101
    Joined Feb 27, 2012
    Levittown, Pennsylvania
    2B6EF28B-310C-4E65-9280-C692338D5024.jpeg Make sure to red Loctite all the converter bolts and check all of your motor mounts. Replace them as necessary. 3 of the mounts are attached to the transmission. I ended up going all solid mounts on my 97 AWD. It was clunking pretty bad after I purchased the car. Here is a picture of my trans mounts


    Street Build 1K  25

    1997 Mitsubishi Eclipse GSX
    awd · automatic · 2G DSM
    Loading...
  16. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    For sure, we’ll change the motor mounts, good thing she isn’t a daily LOL


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  17. BLACK'98DSM

    BLACK'98DSM Proven Member

    1,555
    627
    Joined Feb 9, 2019
    Hoover, Alabama
    Be sure to make a DSM Profile st some point on this site too.:D


    Road Race Build 3K  10  25

    1998 Mitsubishi Eclipse N/T
    fwd · manual · 2G DSM

    104  3

    2008 Tomberlin Crossfire 150R
    rwd · manual · Misc Vehicles

    143  6

    2008 Tomberlin Crossfire (325 swapped)
    rwd · manual · Misc Vehicles
    Loading...
  18. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    Just made one! Lol


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  19. BLACK'98DSM

    BLACK'98DSM Proven Member

    1,555
    627
    Joined Feb 9, 2019
    Hoover, Alabama
    Awesome!:thumb:


    Road Race Build 3K  10  25

    1998 Mitsubishi Eclipse N/T
    fwd · manual · 2G DSM

    104  3

    2008 Tomberlin Crossfire 150R
    rwd · manual · Misc Vehicles

    143  6

    2008 Tomberlin Crossfire (325 swapped)
    rwd · manual · Misc Vehicles
    Loading...
  20. TK's9d2TSi

    TK's9d2TSi Supporting Member

    2,870
    1,060
    Joined Sep 11, 2017
    Cincinnati, Ohio
    You probably know this but don't drive it until it's fixed.


    350  3

    2000 Jeep Cherokee Sport - Classic
    awd · automatic · Misc Vehicles

    373  4

    93 Civic 4 Door -sold-
    fwd · manual · Misc Vehicles

    Street Build 3K  6

    1992 Eagle Talon TSi AWD
    12.625 @ 111.42 · 1G DSM
    Loading...
  21. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    Yea, got the flex plate bolt coming in tomorrow. $17 for one bolt with shipping!


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  22. ThunderChild

    ThunderChild Supporting VIP

    2,881
    963
    Joined Jan 5, 2012
    Rathdrum, Idaho
    Might have been more cost effective to buy a whole set.

    Also, I edited my last post directly after you replied, but check all the bell housing bolts.

    The mounts will be a nice addition, tho they add some vibes to the car.


    Street Build 614  3

    1990 Plymouth Laser N/T
    fwd · manual · 1G DSM

    637  8

    1987 Toyota Pickup/Hilux
    awd · manual · Misc Vehicles

    Street Build 1K  7

    1997 Mitsubishi Eclipse Spyder GST
    fwd · manual · 2G DSM

    2K  0

    1992 Eagle Talon TSi AWD
    manual · 1G DSM

    Street Build 3K  10

    1992 Eagle Talon TSi AWD
    awd · manual · 1G DSM
    Loading...
  23. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    Some vibes?


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
  24. ThunderChild

    ThunderChild Supporting VIP

    2,881
    963
    Joined Jan 5, 2012
    Rathdrum, Idaho
    Vibrations transmitted through the car, as they're stiffer, if you go with the prothane mounts. My 1g with prothanes is pretty shakey inside.


    Street Build 614  3

    1990 Plymouth Laser N/T
    fwd · manual · 1G DSM

    637  8

    1987 Toyota Pickup/Hilux
    awd · manual · Misc Vehicles

    Street Build 1K  7

    1997 Mitsubishi Eclipse Spyder GST
    fwd · manual · 2G DSM

    2K  0

    1992 Eagle Talon TSi AWD
    manual · 1G DSM

    Street Build 3K  10

    1992 Eagle Talon TSi AWD
    awd · manual · 1G DSM
    Loading...
  25. Ivan Garcia

    Ivan Garcia Probationary Member

    16
    1
    Joined Apr 3, 2019
    King City, California
    Ohhh I see


    Street Build 146  1

    1997 Mitsubishi Eclipse GST
    fwd · automatic · 2G DSM
    Loading...
