My turbo manifold mock up complete!

[dsmornothing]

View attachment 3177

View attachment 3178

View attachment 3179

View attachment 3180

View attachment 3181

View attachment 3182

View attachment 3185

View attachment 3186



[eSCAPEist_]

Looking good man, seems like you have a pretty good design going on, can't wait to see the finished product. I'll be looking for other posts of the progress soon, props*



[92AWDHX40]

Looks good i saw a similar set up on the ams evo a few years ago.



[400hp93talon]

Looking F'n amazing so far keep up the great work!!



[dsmornothing]

Thanks everyone! glad your liking it!



[stevenm357]

nice tubular front end can't wait to see int finished.



[gho5tone]

Your exhaust manifold reminds me what shep had in his talon Anyways hope you finish the project!



[ed1380]

Be careful not to suck in a small child



[basdgod]

props, thats so legit



[secongendsm]

Tons of work involved, can't wait to see the finished product!



[dsmornothing]

Thank you everyone!



[jakvett]

Looks good. How did you determine the primary lengths, and are they equal? Do you plan to back purge the welds?



[DirtyDave21]

Kudo's!!! good workmanship!



[dsmornothing]

I wanted longer primaries in hopes that it controls my top end a bit. So I just positioned the collector far enough away and went with it. And they are damn close to equal. Thank you!



[jakvett]

What do you mean by control? Longer primaries shift your power curve lower in the RPM range.



[flyineagletsi]

Dahum son. I didn't think it was going to be this bad! Nice work. Glad to see progress. Keep her up.



[skatershawn]

looks sick.. will you have a heat shield protecting you light?? i would think that turbo would get hot enough to meld you headlight, but thats just me thinking!



[Slippi84]

Nice design. I wish I had the time to try and rig up something like that. Should make for good times.



[SlowGst88]

looks pretty sic man major props



[dsmornothing]

Thanks everyone! This was my first shot at making something like this and I can say Im satisfied! I think an 18g is in the works for next season. this sch 10 is just obnoxious.



[little-razcal]

Very nice work. I wish I had the tools, skills, and money to do a custom build like this. Again great job. I need to ask you though with out sounding like a complete tard, how to you get you line up points for your lights, bumper, fenders, ect..Is this manily more trial and error? Does the front bumper kinda float once attached to the fenders?



[MarsaGSX]

Are you bracing that heavy turbo..or sits just on flange/runners??
COOL Job Man ! how about weight loss with this tube front end??
Venca



[92AWDHX40]

Hey gotta love someone who can try that themselves looks great.
