2G Stock intake pipe ports?

[2gfabiann]

I don’t know what these connect to anyone know?

You must be logged in to view this image or video.



[spyderdrifter]

Those connect to your EVAP canister that should be mounted below your battery.



[2gfabiann]

Those connect to your EVAP canister that should be mounted below your battery.

Both of them?



[spyderdrifter]

I know the larger of the 2 does for sure. The smaller one might, it's been so long since I dealt with those so I'm not 100% positive on the one that has the bolt in it. The tiny one should go to the wastegate solenoid I think.



[2gfabiann]

I know the larger of the 2 does for sure. The smaller one might, it's been so long since I dealt with those so I'm not 100% positive on the one that has the bolt in it. The tiny one should go to the wastegate solenoid I think.

I’ll see tomorrow and let you know thank you!!



[steve]

Three ports plus the BOV pipe. What I remember is the Evap Purge, PCV from rocker cover, and vent from the boost control solenoid?

I did a quick look for a diagram in the FSM but didn't find a good one.



[91RedEagle]

Three ports plus the BOV pipe. What I remember is the Evap Purge, PCV from rocker cover, and vent from the boost control solenoid?

I did a quick look for a diagram in the FSM but didn't find a good one.

That's what those three ports are for on a 1G but I'm not completely certain with a 2G car. It sounds right though.
