1G Electric power steering pump options

[steve-o_95_GST]

106 GTI Power Steering Pump - Peugeot 106 Owners Club

I found this on google. It looks very similar to the one you have, maybe an earlier version?



[gixxerdrew]

The pump portion looks similar, reservoir setup looks different.



[greengoblin]

I think you may have a Renault Clio electric hydraulic power steering .

You must be logged in to view this image or video.

Like the one here:Renault Clio electric hydraulic power steering

Kevin



[greengoblin]

Found this too:eBay Motors: Hydraulic power steering pump, Hot rod electric Custom! (item 260307000150 end time Nov-03-08 17:28:31 PST)



[gixxerdrew]

Yes, it is the renault clio pump. I posted that information somewhere else and then it spread across the internet. That ebay link is the guy I bought mine from he has my picture on the auction as well which I gave him permission to use.



[97EclipseGSX]

In the future I will look into a PWM controller or variable with speed or line pressure changes.

From looking at the video that the seller has on his ebay page it looks like the pump controls the amount of pressure itself. It shoots from 200 psi to 1200 psi when the wheel is turned. Some kind of load detection must be built into the pump. If thats the case I don't think it is a good idea to have more than some sort of on/off switch on the power side.

Awesome find though man I really like. I just wish the resivior wasn't built into it. Does it by chance look like the resivoir can be removed from the pump for a different style?



[99gst_racer]

My system came out great. Just as I hoped this huge pump actually is very quiet and does not pull very much juice. Way less than my radiator fans even.

This is where I had him install it, in the drivers fender, you can see the cooler, 100 amp relay and part of the duct work which I need to finish

You must be logged in to view this image or video.

view from above: in this pic you can see where he welded a -6 fitting to the stock pressure line and normal rubber hose for the low pres side.

The filler is poking through the hole in the stock fender so it can be filled from above per my design.

You must be logged in to view this image or video.

On a side note the standard AN Fitting separated from the hose and I'll be having it redone by the hydraulic shop with pressed crimped fitting. My guess is that pressure was too high 1200+PSI for a 'standard' type AN fitting
View from the top where the fill is:

Any chance you could update these dead pics, Drew? I might be using this exact same pump in the near future, and would love to see how you have yours set-up.



[Blurred Talon]

I'm hoping you can update your pictures too Drew.

I've got an MR2 pump I'm going to use and completely rebuilding my car with new inner and outer tie rods. Hopefully I'll lose the dead spot in the center.



[BLACKCARBON]

EHPS Redone - Honda-Tech

http://www.dsmtuners.com/forums/handling-tech/391777-my-electro-hydraulic-steering-conversion.html

pump is from the 00-05 MR2
seems like a better alternative than the standard mr2



[gixxerdrew]

found some pics finally here:
Drews Gallery



[dsatchell]

A new pump is available. Check out http://www.dsmtuners.com/forums/handling-tech/438221-new-electric-hydraulic-power-steering-pump-ehps.html
