Hey, I'm dealing with a complete overhaul right now, and I'm going off of zero knowlege on the subject.

Does the 99 GS Eclipse not have an ABS Fuse?

I noticed yours didn't even have the wiring hook-up like mine, but I have no idea what was done to this car previously, because my brother had it first was pretty loose on the term "repair" or "upgrade" when he was making his "modifications" to the car.

Last edited by a moderator:
Hey, I feel pretty dumb coming from an electrical background, but I feel like I can't trace the schematics very well. I can't figure out what the full schematics for the electrical issues I'm having look like.

I have a pretty big draw on my 2G, and after pulling fuses, I have narrowed it down to the two 10 A fuses in the engine compartment that are pared together (labeled "I.O.D. Alimentation"), and the 10 A door lock fuse under the driver's side dashboard. I think these are two unrelated circuits, and I think one is the radio (but I want to check everything else as well).

Can someone help me out? In the manual, I keep seeing the circuits named, but I can never find the full circuit diagrams themselves.

That's posted Resources section here. You'll note it's for the 1997 model year and some of the scanning errors makes it harder to follow than a good hardcopy for the right year. I also seem to remember their are pages missing for things the original scanner wasn't interested in or felt were duplicated in other versions.

That's posted Resources section here. You'll note it's for the 1997 model year and some of the scanning errors makes it harder to follow than a good hardcopy for the right year. I also seem to remember their are pages missing for things the original scanner wasn't interested in or felt were duplicated in other versions.
I did notice that, but I can't find the specific manuals I need. I checked Mitsubishi, and they didn't even have them at this point. I'll poke around on ebay, but I prefer electronic when I can get my hands on them. Ctrl+F is my best friend. It just doesn't help here, because I'm tracing schematics that don't seem complete... they just kind of reference certain things.

I don't have any manuals here but I'll be back to home base hopefully next weekend. I think I have a few other 2G manuals in the basement, the only 2G ones in my office are for the 95. If I find a 99 manual we can figure out what you need from it.

I'd watch eBay for the hardcopy set anyway. There are out there but I wouldn't pay $200 for them.
