PROJECT 91 TSi ***Wiring 101***

This site may earn a commission from merchant affiliate links, including eBay, Amazon, and others.

Justins99GSX

15+ Year Contributor
246
3
Oct 31, 2004
Somewhere, Arizona
Well here is some pics that I took after this weekend,

Pic 1 is very discouraging... This is the mess I have left to figure out:barf:

Pic 2 is what keeps me going~! This is what the top side looks like, everything is plugged in on the engine:D





I thought that most of the chasis wiring ended at the fuse box, wrong there~! I may have one group of wires leading from the box twards the tranny not sure yet.... Word to the wise... THIS IS NOT A EASY TASK!!!! Ive put close to 20 hours into this! It is very easy to get overwhelmed looking at all the wires...

Plans for this weekend is to finish preping the engine bay, and finish cleaning the inside... Next weekend she is getting the bay sprayed, as well as the jambs~!

There is some more pics in my photobucket:
http://s117.photobucket.com/albums/o79/JustinsGSX/1991 TSi AWD Project/

Justin

keep us posted on updates, it's looking really good. Your Hard work is definitely going to pay off, big!

stop it, im going to have to do my wiring. Looks good!

Thanks for all the comments~! This wiring is a big headache! Im still looking for some kind of quick connect plug but haven't found anything... I will definately get some more pics up...

Justin
