help hooking gauges up

[djuorna22]

trying to hook up oil psi gauge, where does the stock one go in on the block? is it easy to get to?

next air fuel goes to the o2 sensor on intake?

and electric fuel psi I assume goes to fuel regulator but where is that



[noid]

The stock oil pressure sending unit is on the oil filter housing under the alternator.
The o2 sensor is on the o2 housing located next to the turbo under the exhaust manifold. This can be tapped at the ecu. However using this as an air/fuel gauge is not nearly as accurate as using a wideband gauge and o2 sensor.
As far as fuel pressure. I'm not sure but stock fuel pressure is 43.5 if my memory is correct but I don't believe it's possible to just tap a wire and read actual psi without tapping into a fuel line.

If you use the SEARCH function much better information can be found than what I have provided . Good luck.



[GoodbyeSTI]

I get oil pressure from the head, that's where the least psi is seen.



[Seamus]

For fuel pressure, you need an aftermarket fpr to get a signal from there. Otherwise, you can use adapters on your fuel lines, or tap the rail. You can really get you FP signal from anywhere. For you air to fuel, I don't know what kind you have but if its wideband you need to wire up the controller and or gauge, and the sensor goes in place of your original in the exaust or you weld in a new bung.



[simplejoe]

For a wideband you want it atleast 36" from the turbo. You put it in the 02 housing you can burn up the sensor. I've heard people putting it in the housing and having great success, but I'd just weld a bung on after the flex pipe.
