Drag Race Build: 90 Eagle Talon auto Drag build

wvturbo2 · 03-13-2012, 09:28 PM

The Car is a 90 Eagle Talon Tsi awd some of you may have seen the car around a few other threads as I've had it for a years. It's been a long hard road with many ups and downs. Last year the season ended with a best 1/8th mile pass of 7.0@114mph. I ended up shearing every tooth off of 3rd gear prior to making it to the 1/4.
Here is a run down on the build.
4g63t 2.0 turbo
standard wiseco 9:1 pistons
Manley rods
Fully balanced block
280 cams bc singles (soon to be switched to manley duals)
DMF custom top mount foward facng exhaust manifold
dmf intake manifold
Haley ported head.
The car was a 5 speed car with QM twin disk and shep trans. It is in the process of being switched to auto.
I also picked up some sponsors this year which are deMartino fabrications and Ostar motorsports
so far picked up a set of bc racing coilovers with custom spring rates from Ostar.
Along with the diy afco upper and lower control arms.
DMF and myself will be installing all the parts including the new 2g auto with kiggly 6bolt to 2g transmission kit, sinister speed 8" converter with 4500 stall, kiggly front clutch kit, and blue wire mod.
The goal for the car is to jump from the previous best of only an 7.0 pass into the low 6's in the 1/8. The car is hopefully headed the right direction and with the help of deMartino fab and Ostart hopefully this will be one of the best seasons yet. I will be keeping this updated with pictures of parts install and progress as the season goes on.

cpoindexter · 03-14-2012, 07:51 AM

looks like a great build, lets get some more pics!

wvturbo2 · 03-15-2012, 08:57 PM

Here are some more pics of the car. Selling my cams and trying to figure out something to upgrade to now. I'm trying to get all the parts I need together so when we pull it off the trailer it will be ready to get knocked out without waiting for much. I will keep posted as soon as I get more parts in or the car comes off the trailer.

Pipnorcali · 03-15-2012, 09:09 PM

Sweet ride

wvturbo2 · 05-10-2012, 11:14 AM

Finally got the car off the trailer and got started on it. So far I have the coilovers on, the ratchet shifter mounted and one side of the upper and lower control arms done. Here are some pics

96' Eclipse GS · 05-10-2012, 04:50 PM

I LOVE THE TURBO FACING THE FRONT! I just fell in love....haha! Great Build! I always loved the idea of cutting the hood above on the hood, for example, where the top of the turbo touches the bottom, so people say, "OH SHIT!"

cpoindexter · 05-11-2012, 12:22 AM

what turbo are you running?

turboglenn · 05-11-2012, 01:00 AM

Glad to see you makea buiild thread about her! I have been wodeing where you've been

IIRC he'sn running a PTE6765 turbowhich is the upgrade from the 6776 i had, a solid 750+HP turbo

wvturbo2 · 05-11-2012, 09:39 AM

Quote:

Originally Posted by turboglenn

Glad to see you makea buiild thread about her! I have been wodeing where you've been

IIRC he'sn running a PTE6765 turbowhich is the upgrade from the 6776 i had, a solid 750+HP turbo

Yea I've been slacking on the build thread or even the build for that matter. Figured I'd post some updates now that the car is off the trailer and actually getting worked on.
Head is off the car changing out the bc singles and bc 280's to kiggly beehives and gsc s3 cams. Got the head checked and a new head gasket for it. I have a week vacation from work coming up and plan on getting alot more done. I will make sure to actually update this thread as the car keeps progressing.

wvturbo2 · 05-28-2012, 12:30 PM

motor is back together transmission is back together and in car with converter in. Working on getting axles right having trouble with the passenger axle length right now. I'll add some pics of progress soon. We had an oil fire in the garage which resulted in my buddy getting second degree burns. He is fine and we will get back on the car before too long.

tim3kgt · 05-28-2012, 04:26 PM

can you feel a difference without the rear sway bar? im thinking of deleting mine in foavor of some AFCO lower arms...

wvturbo2 · 05-28-2012, 04:43 PM

Quote:

Originally Posted by tim3kgt

can you feel a difference without the rear sway bar? im thinking of deleting mine in foavor of some AFCO lower arms...

Haven't deleted rear sway bar or driven car yet. When I get it running remind me and I'll let you know

wvturbo2 · 05-31-2012, 12:39 PM

Progress pics

wvturbo2 · 06-16-2012, 08:30 AM

New parts in

My car and the daily

TSimage · 06-16-2012, 10:45 AM

Nice build, what suspension is that?

BTW, I'm a Lightning owner so you can only guess how fond I am of the TBSS (sarcasm...) lol.

wvturbo2 · 06-16-2012, 10:58 AM

Bc Racing coilovers and the diy afco control arms.
I'm a fan of the lightning, but the tbss has all the room and power I need!

RipperXX · 06-18-2012, 09:28 AM

What FMIC is that? It looks like it would allow you to keep the fog lights, which is one reason im interested. Also, I got a set of FD wheels to go on my 1g when I get back to the states. What size spacers did you need to get them to clear? And did you NEED or use extended studs? aftermarket lugs needed?

thx

GRAVEDIGGER · 06-18-2012, 09:38 AM

I really noticed this car last year at the DSM Shootout and it's only getting better this year. Nice work!

Can't wait to see it get up and running fully and I hope to see it at the Shootout again this year. Way to represent the DSMs in WV!

wvturbo2 · 06-18-2012, 07:56 PM

Quote:

Originally Posted by RipperXX

What FMIC is that? It looks like it would allow you to keep the fog lights, which is one reason im interested. Also, I got a set of FD wheels to go on my 1g when I get back to the states. What size spacers did you need to get them to clear? And did you NEED or use extended studs? aftermarket lugs needed?

thx

The intercooler is a cx racing 5" thick core with the original outlets moved from the bottom to straight back. It isnt something you could throw in without modification. As for the fd wheels I think it was 10mm spacers and some grinding on the control arms. Don't quote me on the spacers though. You might wanna do some searching. No extended studs or other modification to fit those. They use acorn style lug nuts.

Quote:

Originally Posted by GRAVEDIGGER

I really noticed this car last year at the DSM Shootout and it's only getting better this year. Nice work!

Can't wait to see it get up and running fully and I hope to see it at the Shootout again this year. Way to represent the DSMs in WV!

Thanks last year was my first time bringing a car to the shoot out . Trying to get this thing in full force for the shoot out this year! Thanks ! Trying to do big things in a two car garage lol

Got a little bit done today !

slow91 · 06-19-2012, 08:51 AM

Hey is that black on the bumper used for to set music papers on when u play violen??? Lol looks good man! You guys get the axle figured out?

wvturbo2 · 06-19-2012, 08:53 AM

Quote:

Originally Posted by slow91

Hey is that black on the bumper used for to set music papers on when u play violen??? Lol looks good man! You guys get the axle figured out?

Well dee made it out last night and we made some progress hoping to have axle situation figured out this eve

Ok fitment issue looks to be solved with a little machine work. Will be testing strength as we goto the track. If anyone else attempts this swap and runs into same issues as me the custom axle will be available for purchase

Lowered and control arms adjusted

wvturbo2 · 06-21-2012, 09:19 AM

A little more progress made. Timing belt is on, transfer case, and converter bolts in. Hoping to stay on top of it and start getting the car down the home stretch!

slow91 · 06-21-2012, 03:05 PM

Woo hoo!!!!

wvturbo2 · 06-22-2012, 11:14 PM

More progress

wvturbo2 · 06-25-2012, 07:17 AM

wvturbo2 · 07-09-2012, 02:45 PM

WEll got the car fired up. Storm rolled in a screwed up progress on getting it tuned in to idle. Have to make user defined setting for the 7 bar map sensor. Starter is making some noise when engaging so going to have to do some modifying on that. I'll post up some pics of the new downpipe. As soon as its nice out and car is idling on its own I'll post up a start up video.

wvturbo2 · 07-12-2012, 07:05 AM

robertbaxley03 · 07-12-2012, 10:18 AM

Nice progress on the car. I do however have one concern.

I also used the AFCO parts to make some adjustable upper control arms for my 1g. I found that after less than 300 miles, the rod end links had developed a considerable amount of play. If I grabbed the tire and wiggle, the heim joint would actually make an audible ticking noise.

I contacted AFCO to see what the "service limit" for play would be and they could not provide me with an answer. Instead they sent me new heim joints. I started by checking them for play and right out of the box, the joints had a considerable amount of play and would make an audible tick.

I ended up pulling these off of my car to check their condition and replace them with the stock uppers and some poly bushings. What I found was a little scary. The inner race had developed wear/heat marks and they would catch your nail when rubbing it over. The marks where mostly brown with a hint of blue. I do not know how long these would have lasted and I am glad that I did not find out.

I am only voicing this concern because I saw the pictures of the parts you where using and they are the exact same ones. There will be a video of the damage soon to come.

Robert

wvturbo2 · 07-12-2012, 10:42 AM

We will have to keep an eye on it. I appreciate the heads up. The car won't be on the street so hopefully it'll take awhile to put much wear on them

robertbaxley03 · 07-12-2012, 02:25 PM

Mine hardly ever hits the streets. It only sees them when I am traveling to and from the track or tuning out an issue. I hope that you have better results than I did.

Best way I found to check it is raise rear off the ground, then grab the tire in all directions while pushing and pulling. I found what was making the noise with my handy automotive stethoscope. I set up a dial gauge to find .004 of play in one and .003 in the other. Let us know if you find anything.

Robert
