Street Build Orca - 11 sec street rippa

Year
1992
Model/Trim
Eagle Talon TSi AWD
Orca - 11 sec street rippa

Specs & Mods

Ownership Status
Currently Own
Turbo Type
16g
Drivetrain
AWD
Transmission Type
Manual
Build Type
  1. Street
Mods-Bolt-on
Block rebuilt 7/2020 130K
Wisco HD 8.5:1 85.5mm pistons
Eagle H beam rods
Kiggly Girdle
Polished stock crank
ACL Race Bearings
PTW Clearance .0045
Rod bearing .002
Main bearing .018 - .002

Head
ARP L19 studs
Stage 1 ported head - decked .003 3/2019
Kelford 272
OEM composite HG 7/2020
Evo exhaust valves - valves lapped 3/2019
Fidanza cam gears

Turbo
68hta V2
Cerakoted fp manifold and turbo housing
Tial MVR 44mm open dump
JMFab O2
Full 3” exhaust
Hallman's manual BC

Link V3 *SD* *Ethanol*
AUS 1600cc injectors
Fuel Lab 515 AFPR 43.5 bfp 6an in&out from AEM rail & Fuelab 818 filter w SS element
525 hellcat rewired
FMIC
Tial Q 50mm BOV
EGR deleted
Pcv check valve
Dual catch can
Solid Urethane mounts and inserts for front
90 amp alt 100 amp fuse
Mishimoto radiator w stock ps fan & Spal VA09 AP50/C-27A slim fan
Innovate mtxl plus (new sensor 11/2020)
Greddy egt
Auto meter boost gauge
Flex fuel sensor
Ngk blue wires 3/2018
Ngk plugs ES 3/2019
K&N filter
Competition light weight flywheel resurfaced 12/2019
New ACT-MB010X 2600 w sprung street disc 12/2019
Mods-Engine
Wisco HD 8.5:1 85.5mm pistons
Eagle H beam rods
Kiggly Girdle
Polished stock crank
ACL race bearings
ARP hardware
Kelford 272
Stage 1 ported head
Evo exhaust valves
Mods-EMS & Logging
V3 SD
Mods-Drivetrain
Shep stage 3 w welded diff
Mods-Handling
D2 coilovers
3SX rear upper adjustable control arms
All new bushings up front 11/2020
Adjustable rear upper control arms
Parts Wishlist
Shortshifter
Big brake kit
Background
Bought in October 2017 w 126K

Performance

1/4 Mile E/T
12.2
1/4 Mile MPH
120
Timeslip Video Link
Watch Video
Timeslip Photo Link
Timeslip Details
Time slip printer malfunction

Videos

  • 802727C4-5B70-458E-BFC7-4B46884ACEAC.jpeg
    1.3 MB · Views: 302
  • 1E7EC060-3047-433C-9D24-F217B7874F89.jpeg
    1.3 MB · Views: 208
  • C94E756B-269F-4F3A-9AC6-83837ABDCC62.jpeg
    1.7 MB · Views: 36
  • C6E9B0B4-E522-4AB6-92D7-C422D49D13D3.jpeg
    2.8 MB · Views: 32
  • 221D9E80-6DE0-4D24-B26C-C518E4935545.jpeg
    2.3 MB · Views: 33
