Changing valve stem seals [Merged 8-7]

Posted by tbird, Dec 29, 2003
Newbie Forum - Beginner DSM modification questions and discussions. Common, repetitive, and general discussions will get dumped here from other tech forums. Unless you're a Probationary member you shouldn't post threads here.

  1. tbird

    tbird Proven Member

    Joined:
    Nov 10, 2002
    Posts:
    160
    Likes Received:
    0
    , IndianaUS
    I need some tips on how to change the valve seals... im gonna be doing this for a friend how much time can i expcent doing this. and what tools will be needed.....
    #1
  2. sonicnofadz

    sonicnofadz Proven Member

    Joined:
    Sep 12, 2003
    Posts:
    747
    Likes Received:
    12
    Baltimore, Maryland
    check out :
    http://www.vfaq.com

    They have a tutorial on this. Your going to need to take off the valve cover, remove the camshafts, and remove the valve springs. You will need some type of valve spring compressor (home made or professional tool). Its really not a whole lot of work, but if you don't have the right tools, it can prove to be very time consuming, or impossible.
    #2
  3. Defiant

    Defiant DSM Wiseman

    DSM Profiles:
    1
    Joined:
    Jan 13, 2003
    Posts:
    25,202
    Likes Received:
    93
    glorious Galt, California
    Try checking the real link:

    http://vfaq.com/mods/Valvestem-seals.html

    but thanks for the lame steer.
    #3
  4. sway2this

    sway2this Proven Member

    Joined:
    Jul 1, 2004
    Posts:
    56
    Likes Received:
    0
    kentwood, Louisiana
    how hard is it to change the valve seals on my 95 n/t gs?
    thanks guys!!
    charles
    #4
  5. x camaro owner

    x camaro owner Banned Member

    Joined:
    May 1, 2004
    Posts:
    340
    Likes Received:
    0
    mokena, Illinois
    depends how slick you are some people pressureize the cylinder to keep the valves up then change them
    #5
  6. SnoopySLR

    SnoopySLR Proven Member

    DSM Profiles:
    1
    Joined:
    Nov 14, 2002
    Posts:
    1,115
    Likes Received:
    3
    Highland, Michigan
    You need a C clamp style Valve Spring Compresser. I just took my head of and gave it to the machine shop. They cleaned it and replaced the seals for $20. They're cheap though. It might cost about $20-$40, its not much work for them.
    #6
  7. JaxTalonTSi

    JaxTalonTSi Proven Member

    Joined:
    Sep 24, 2004
    Posts:
    118
    Likes Received:
    9
    Jacksonville, Florida
    What's up, guys? I will be replacing the valve seals in my car shortly, and I want to know the difficulty of changing them on these cars. I've changed valve seals on small block Chevrolets before (fairly easy), but I heard it's a pain in the ass with these. I've even heard it's best to take the cylinder head OFF to do this. I've browsed through DSMTuners.com tech threads, and read one on this subject, and it involved making a special tool to do the job. It really looks like a pain in the ass, and I'm wondering if there is another way to go about doing this. Is taking the cylinder head off making TOO much work for myself?

    Thanks for your time

    :talon:
    #7
  8. midnght

    midnght Proven Member

    Joined:
    Nov 14, 2002
    Posts:
    2,274
    Likes Received:
    1
    Hagerstown, Maryland
    It is not a easy job. It takes alot more to do so on the DSM than a Chevy.

    I don't know what the tool is for. Maybe to help get the retainer cap back on. The shims can be a bi***. I never had to use a special tool to get it off. But, I never had to put the shims back in, the shop that decks my head does that.
    #8
  9. JaxTalonTSi

    JaxTalonTSi Proven Member

    Joined:
    Sep 24, 2004
    Posts:
    118
    Likes Received:
    9
    Jacksonville, Florida

    So do you think I should just pull the head?
    #9
  10. trevor_shiggs

    trevor_shiggs Proven Member

    DSM Profiles:
    1
    Joined:
    Jul 1, 2004
    Posts:
    64
    Likes Received:
    0
    Duncan, B.C._Canada
    #10
  11. midnght

    midnght Proven Member

    Joined:
    Nov 14, 2002
    Posts:
    2,274
    Likes Received:
    1
    Hagerstown, Maryland
    If you can find the tool to get the springs on without removing it, i say leave it on.


    there is an easier way to remove the retainers than that. it is just alittle more "brutal" than most would use, but works just as good.
    #11
  12. JaxTalonTSi

    JaxTalonTSi Proven Member

    Joined:
    Sep 24, 2004
    Posts:
    118
    Likes Received:
    9
    Jacksonville, Florida
    Yeah, that's the tool I was looking at earlier. It's cool how he did it, but knowing me, It wouldn't come out half as good, and I'd still end up getting so pissed I'd take a sledgehammer to my cylinder head. I need to start looking for that C-clamp valve spring compressor thing atleast. :confused:
    #12
  13. midnght

    midnght Proven Member

    Joined:
    Nov 14, 2002
    Posts:
    2,274
    Likes Received:
    1
    Hagerstown, Maryland
    That is how you remove the springs :thumb:


    I would just remove the head. Less stress and more room to work. It is pretty difficult to install the retainers with the head on.
    #13
  14. JaxTalonTSi

    JaxTalonTSi Proven Member

    Joined:
    Sep 24, 2004
    Posts:
    118
    Likes Received:
    9
    Jacksonville, Florida
    #14
  15. Tallen

    Tallen Proven Member

    Joined:
    May 28, 2002
    Posts:
    2,237
    Likes Received:
    4
    Ashburn, Virginia
    Pull the head. give to a lil porting love while your at it.
    #15
  16. bmxrider154

    bmxrider154 Proven Member

    Joined:
    Oct 25, 2004
    Posts:
    156
    Likes Received:
    0
    Cincinnati, Ohio
    How big of a job is it to replace my valve seals, besides the tool? How much would it cost for someone to do it?
    #16
  17. 2.4 turbo Hyped

    2.4 turbo Hyped Proven Member

    Joined:
    Jan 6, 2004
    Posts:
    545
    Likes Received:
    2
    Portland, Oregon
    Cost is about 20 bucks to make the tool to compress the valve springs yourself and about 10 bucks for the seals. The rest is time and labor.
    #17
  18. blitz43

    blitz43 Awaiting Email Verification

    Joined:
    Jun 15, 2004
    Posts:
    218
    Likes Received:
    1
    chicago, Illinois
    hey guys i believe my valve stem seals went bad because puffs of blue smoke (oil)
    comes out of my exhaust when my car comes to a stop and then pull away
    but not when im driving it stops

    my question is how hard is it to install new seals and do i really have to remove my head from the block and if i keep driving the car how bad this can get? :(
    #18
  19. Alex_95TSI

    Alex_95TSI Proven Member

    Joined:
    Dec 27, 2004
    Posts:
    92
    Likes Received:
    0
    San Jose, California
    You mean the gasket/seals around the spark plug holes?

    Sorry to say this but oil cant leak from your valve cover to your combustion chamber.
    #19
  20. Defiant

    Defiant DSM Wiseman

    DSM Profiles:
    1
    Joined:
    Jan 13, 2003
    Posts:
    25,202
    Likes Received:
    93
    glorious Galt, California
    He just might mean valve stem seals.

    How many miles on the motor? It may be guide seals, or it may be rings, or it may be ?
    #20
  21. G9S1X

    G9S1X Proven Member

    Joined:
    Mar 19, 2004
    Posts:
    67
    Likes Received:
    0
    Fort Lauderdale, Florida
    Take off the head and take it to a head specialist, have them evaluate it. I got all new seals, guides, valves, hot tanked, and resurfaced all for just under 350$ :thumb: . While your in there check for block deck warpage, I believe anything under 0.005 inch (0.127mm) is acceptable. You do not wanna bolt down a resurfaced head to a warped block. Also check for obvious cracks in the block, extreme ridges in the CC, and check for piston play. You might want to go all out and do a bottom end rebuild with all new bearings, seals, pistons, and piston rings. Good Luck :)
    #21
  22. FORMONTOYA

    FORMONTOYA DSM Wiseman

    DSM Profiles:
    1
    Joined:
    Oct 7, 2004
    Posts:
    1,998
    Likes Received:
    55
    Houston, Texas
    i am in the process of upgrading my turbo because it took a dump in sept 04. upon removal of exhaust mani i saw that i also had bad stem seals. during the search i was pointed to a tool that can remove stem seals without having to take the head off.
    http://dsmtuners.com/forums/showthread.php?t=164239
    post #5. and post #6 will give link to tool. i chose to take the head off anyway to do further work on it, but you might be able to rent/find someone with one if on a budget.
    jim
    #22
  23. blitz43

    blitz43 Awaiting Email Verification

    Joined:
    Jun 15, 2004
    Posts:
    218
    Likes Received:
    1
    chicago, Illinois
    well when i come to a stop i see smoke THiCK smoke come out the exhuast a mixture of whiteish and blushish smoke which could also indicate a blown headgasket
    #23
  24. Red 2g GSX

    Red 2g GSX Proven Member

    Joined:
    Oct 11, 2004
    Posts:
    70
    Likes Received:
    0
    Orange Park, Florida
    Hey when I build my head i made my own compressor. I used a 8" C-Clamp and i got a 13/16 spark plug socket (its what fit the valve the best) and cut a notch in the side of the socket so i can reach the retainers and I drilled and taped a hole on the c clamp and bolted the socket to the clamp. Worked like a champ!

    If you dotn understand let me know.

    Vic
    #24
  25. blitz43

    blitz43 Awaiting Email Verification

    Joined:
    Jun 15, 2004
    Posts:
    218
    Likes Received:
    1
    chicago, Illinois
    im gonna have my school do a leakdown test to confirm what is bad either the headgasket or seals


    my car has 100,013 miles on the clock

    im thinking about selling and just getting another but thats my last resort
    #25
