1st and 2nd picture have the skidplate laying on the floor. The part seen covers til about the passenger compartment, it's 1/8" aluminum, with 2 additional 3/16" plates directly under the engine.

From there a 1/8" plate runs to the rear axles, with 5 rows of 3 holes for venting.

Covering the rear axles and rear driveline components are 1/8" polyurethane sheets.



____________________________
90 Talon AWD Rally
11 STi
05 Lotus Elise. Sold

Last edited by PotatoFlakeSTi; 07-20-2013 at 08:24 PM. Reason: Not sure why I thought it was steel, it's obviously aluminum.

mark post as helpful recommend reputation points    Reply With Quote
Old 11-30-2011, 07:06 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #22 (permalink)
DSM Wiseman


jtmcinder's Avatar
Car: Evo X GSR
Registered: Nov 2003
Tech Posts: 5,208
Classifieds Rating: 0
Reputation: You can trust this leader of the site
Why did I even ask.... I'm an idiot sometimes. Thanks.

I went with 3/16 aluminum for my plate. It seemed a good balance between weight and strength.

mark post as helpful recommend reputation points    Reply With Quote
Old 11-30-2011, 10:39 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #23 (permalink)
Supporting Member


Kreez's Avatar
Registered: Apr 2010
Tech Posts: 668
Photos: 11
Classifieds Rating: 5
Reputation: Kreez is pretty helpful and trustworthy
It's looking good man!

Give me a shout if you need an extra hand


____________________________
Dan

'90 Laser RS Turbo
'91 Talon TSi
'92 Talon TSi AWD
View photos of this member's car

mark post as helpful recommend reputation points    Reply With Quote
Old 12-20-2011, 11:22 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #24 (permalink)
Supporting VIP


Piranhaman33's Avatar
Registered: Jun 2003
Tech Posts: 42
Photos: 10
Classifieds Rating: 5
Reputation: Piranhaman33 is an unknown
Send a message via AIM to Piranhaman33
Nice car man!! I'd love to rally a 1g, specially through the Mojave Desert. I'm also loving the vid.
View photos of this member's car

mark post as helpful recommend reputation points    Reply With Quote
Old 01-04-2012, 06:08 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #25 (permalink)
Proven Member


PotatoFlakeSTi's Avatar
Registered: Oct 2011
Tech Posts: 170
Classifieds Rating: 3
Reputation: PotatoFlakeSTi is an unknown
Good thing I bought the prothane motor-mount inserts;
Drivers side mount;



Passenger side mount;



Prothane polyurethane inserts installed;




Also for funsies, car jacked up... wheels are still touching the ground;



Oh and here's my "front motor mount".

I'll assume the PO did this;


____________________________
90 Talon AWD Rally
11 STi
05 Lotus Elise. Sold

mark post as helpful recommend reputation points    Reply With Quote
Old 01-05-2012, 10:30 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #26 (permalink)
Supporting VIP


Piranhaman33's Avatar
Registered: Jun 2003
Tech Posts: 42
Photos: 10
Classifieds Rating: 5
Reputation: Piranhaman33 is an unknown
Send a message via AIM to Piranhaman33
Oh and here's my "front motor mount".

I'll assume the PO did this;
[/QUOTE]



What the hell?
View photos of this member's car

mark post as helpful recommend reputation points    Reply With Quote
Old 01-05-2012, 10:35 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #27 (permalink)
Proven Member


ilco187's Avatar
Registered: Jan 2009
Tech Posts: 1,091
Photos: 66
Classifieds Rating: 6
Reputation: ilco187 is pretty helpful and trustworthy
Send a message via Yahoo to ilco187
Oh your the rally car guy. looking at the 3rd pic down from the top of the thread, that looks like thats why he did it cause it must have broke something being the front subframe and core support looks really tweaked in that photo.


____________________________
kyle.
View photos of this member's car

mark post as helpful recommend reputation points    Reply With Quote
Old 01-06-2012, 12:17 AM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #28 (permalink)
Proven Member


PotatoFlakeSTi's Avatar
Registered: Oct 2011
Tech Posts: 170
Classifieds Rating: 3
Reputation: PotatoFlakeSTi is an unknown
Quote:
Originally Posted by Piranhaman33 View Post
What the hell?
I know right? Lmao.



Quote:
Originally Posted by ilco187 View Post
Oh your the rally car guy. looking at the 3rd pic down from the top of the thread, that looks like thats why he did it cause it must have broke something being the front subframe and core support looks really tweaked in that photo.
Seems about right.

Oh well. It'll do until it fails completely.


____________________________
90 Talon AWD Rally
11 STi
05 Lotus Elise. Sold

mark post as helpful recommend reputation points    Reply With Quote
Old 01-06-2012, 01:34 AM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #29 (permalink)
Supporting VIP


Piranhaman33's Avatar
Registered: Jun 2003
Tech Posts: 42
Photos: 10
Classifieds Rating: 5
Reputation: Piranhaman33 is an unknown
Send a message via AIM to Piranhaman33
At least you've got inserts on the other mounts. On another note i'm really liking the rally computer.
View photos of this member's car

mark post as helpful recommend reputation points    Reply With Quote
Old 01-06-2012, 01:52 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #30 (permalink)
Proven Member


Tyeler18's Avatar
Registered: Dec 2008
Tech Posts: 1,931
Classifieds Rating: 10
Reputation: Tyeler18 is pretty helpful and trustworthyTyeler18 is pretty helpful and trustworthy
Looks like quite a fun project! Ever thought about going Water to air intercooled? Don't know what you're rules are you need to follow, but the W/A will allow you to keep a free radiator and not have to worry about ruining a FMIC, quicker spool and more efficient cooling as well.

Like Kreez said, if you ever want any help let me know. I'm not too far away and this is the kind of racing I'd love to get into!

mark post as helpful recommend reputation points    Reply With Quote
Old 01-06-2012, 03:13 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #31 (permalink)
Proven Member


PotatoFlakeSTi's Avatar
Registered: Oct 2011
Tech Posts: 170
Classifieds Rating: 3
Reputation: PotatoFlakeSTi is an unknown
Quote:
Originally Posted by Tyeler18 View Post
Looks like quite a fun project! Ever thought about going Water to air intercooled? Don't know what you're rules are you need to follow, but the W/A will allow you to keep a free radiator and not have to worry about ruining a FMIC, quicker spool and more efficient cooling as well.

Like Kreez said, if you ever want any help let me know. I'm not too far away and this is the kind of racing I'd love to get into!
Well, as most privateer rally cars I'm trying to stay with a "Keep It Simple, Stupid" approach, so for now a chargecooler is not in the plans.

I hope to have anti-lag programmed EVENTUALLY, so spool-time will cease to be an issue at that point... Of-course I'll need to shed heat better at that point.

If you're interested in the scene, and want to get involved I'd implore you to visit the ColoradoRallyRacing.com forum. It's still pretty new, but there are some knowledgeable guys on there. (Working on setting up a NASA Rally Sprint in Steamboat, CO)
They also have information on the Colorado hill-climbs, some not too far from you.

On that note though, I will be heading to New Jersey permanently around the beginning of March, along with the car.


____________________________
90 Talon AWD Rally
11 STi
05 Lotus Elise. Sold

mark post as helpful recommend reputation points    Reply With Quote
Old 02-04-2012, 09:41 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #32 (permalink)
Probationary Member


ConcowTSI's Avatar
Registered: Oct 2011
Tech Posts: 23
Photos: 5
Reputation: ConcowTSI is an unknown
awesome thread, love the car man, what kind of coilovers are those? i recently got a 95 tsi and am really really looking forward into rallying it, first thing i want to do is suspension. could we get some pics of the rear skid plating also?


____________________________
95 Tsi YEAH; I call my TSI the Seagle, SO WHAT!
View photos of this member's car

mark post as helpful recommend reputation points    Reply With Quote
Old 02-13-2012, 05:27 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #33 (permalink)
Proven Member


PotatoFlakeSTi's Avatar
Registered: Oct 2011
Tech Posts: 170
Classifieds Rating: 3
Reputation: PotatoFlakeSTi is an unknown
Quote:
Originally Posted by ConcowTSI View Post
awesome thread, love the car man, what kind of coilovers are those? i recently got a 95 tsi and am really really looking forward into rallying it, first thing i want to do is suspension. could we get some pics of the rear skid plating also?
Hey Concow,

The suspension is HotBits DT2 with Gravel valving and softish springs with helpers, 2-way adj and exterior expansion canisters.
I'm currently not entirely sure of the stiffness on the springs(lb wise), but I'll look into it.

Suspension should definitely be the first thing you do on a rally car (after safety items, ofcourse!), since you can run upgraded suspension in production class. Although I think the reason you see more 1g's on the dirt is because they have more travel available in the front.

I'll post up some pictures of the mid/rear-ish skidplating (which is actually just a few urethane sheets from the doors back)
The fuel-tank has a steel tank fitted around it, which will work well for when I decide to get a fuel cell as well.

Edit: Meant to say that I'll post pictures when the car arrives in New Jersey... Being shipped across the country atm.


____________________________
90 Talon AWD Rally
11 STi
05 Lotus Elise. Sold

mark post as helpful recommend reputation points    Reply With Quote
Old 02-13-2012, 05:36 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #34 (permalink)
Banned Member


Sebba's Avatar
Registered: May 2006
Tech Posts: 538
Classifieds Rating: 0
Reputation: Sebba is an unknown
Send a message via AIM to Sebba Send a message via MSN to Sebba
What about this? Better spool, and never have to worry about the fins clogging.


mark post as helpful recommend reputation points    Reply With Quote
Old 02-13-2012, 05:49 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #35 (permalink)
Proven Member


PotatoFlakeSTi's Avatar
Registered: Oct 2011
Tech Posts: 170
Classifieds Rating: 3
Reputation: PotatoFlakeSTi is an unknown
Quote:
Originally Posted by Sebba View Post
What about this? Better spool, and never have to worry about the fins clogging.

That set-up looks pretty good, any more information on it?


____________________________
90 Talon AWD Rally
11 STi
05 Lotus Elise. Sold

mark post as helpful recommend reputation points    Reply With Quote
Old 02-13-2012, 05:55 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #36 (permalink)
Banned Member


Sebba's Avatar
Registered: May 2006
Tech Posts: 538
Classifieds Rating: 0
Reputation: Sebba is an unknown
Send a message via AIM to Sebba Send a message via MSN to Sebba
Yeah the owner is Mike, AKA JAXWHITE1G. He is a master when it comes to metal/mechanics. He fabricated the whole thing himself, IMO that's how they should have been from the factory.

I've only ridden in that car once, but I was impressed by how well everything was done. He was running a 20g at the time and it spooled like a mofo. I think he added a draw fan under it, but I can't recall. I know he's running it with the GM-MAF on the intake like my car, but I don't know if he recirc'd it. I could be wrong, but I think he just picked up a small core off of eBay and make it work.

Unique, functional, effective, and best of all better performing.

mark post as helpful recommend reputation points    Reply With Quote
Old 02-13-2012, 07:44 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #37 (permalink)
Proven Member


PotatoFlakeSTi's Avatar
Registered: Oct 2011
Tech Posts: 170
Classifieds Rating: 3
Reputation: PotatoFlakeSTi is an unknown
Quote:
Originally Posted by Sebba View Post
Yeah the owner is Mike, AKA JAXWHITE1G. He is a master when it comes to metal/mechanics. He fabricated the whole thing himself, IMO that's how they should have been from the factory.

I've only ridden in that car once, but I was impressed by how well everything was done. He was running a 20g at the time and it spooled like a mofo. I think he added a draw fan under it, but I can't recall. I know he's running it with the GM-MAF on the intake like my car, but I don't know if he recirc'd it. I could be wrong, but I think he just picked up a small core off of eBay and make it work.

Unique, functional, effective, and best of all better performing.
So he's running his GM MAF pre-turbo?

I'm not terribly worried about spool-time, as the car won't be still much and shouldn't be low on revs often... When the eventual anti-lag is programmed all I'll have to worry about it cooling and "ease of fixability"


____________________________
90 Talon AWD Rally
11 STi
05 Lotus Elise. Sold

mark post as helpful recommend reputation points    Reply With Quote
Old 02-15-2012, 12:40 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #38 (permalink)
Proven Member


PotatoFlakeSTi's Avatar
Registered: Oct 2011
Tech Posts: 170
Classifieds Rating: 3
Reputation: PotatoFlakeSTi is an unknown
Alright, car is in NJ.

If you're in the Central NJ area come by and I'll get some beers and a pizza and we can talk cars!

Should have a welder soon!


____________________________
90 Talon AWD Rally
11 STi
05 Lotus Elise. Sold

mark post as helpful recommend reputation points    Reply With Quote
Old 02-15-2012, 03:06 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #39 (permalink)
Banned Member


Sebba's Avatar
Registered: May 2006
Tech Posts: 538
Classifieds Rating: 0
Reputation: Sebba is an unknown
Send a message via AIM to Sebba Send a message via MSN to Sebba
Quote:
Originally Posted by PotatoFlakeSTi View Post
So he's running his GM MAF pre-turbo?

I'm not terribly worried about spool-time, as the car won't be still much and shouldn't be low on revs often... When the eventual anti-lag is programmed all I'll have to worry about it cooling and "ease of fixability"
Yeah, pre-turbo. It'd be awesome to see another top mount setup.

mark post as helpful recommend reputation points    Reply With Quote
Old 03-02-2012, 12:40 PM Show Printable Version Show Printable Version   Email this Post to a Friend Email this Post      #40 (permalink)
Proven Member


2nd Gen Mnstr's Avatar
Registered: Feb 2012
Tech Posts: 26
Photos: 6
Classifieds Rating: 0
Reputation: 2nd Gen Mnstr is an unknown
Yeeea. im thinkin tha motor mount is dead.
View photos of this member's car

mark post as helpful recommend reputation points    Reply With Quote
Reply

Bookmarks

Thread Tools



» Recent DSM Photo
» Current Poll
How many times have you been to the Shootout?
1 - 39.86%
167 Votes
2-5 - 41.77%
175 Votes
6-10 - 10.50%
44 Votes
11-15 - 3.10%
13 Votes
16-20 - 4.77%
20 Votes
Total Votes: 419
You may not vote on this poll.
» Online Users: 482
160 members and 322 guests
Most users ever online was 1,704, 03-17-2008 at 09:11 PM.
DSMtuners Main Sections
DSM Forums
DSM Regional Forums
DSM Builds/Journals
DSM Articles
DSM Tech Guides
DSM Upgrade Paths
DSM Parts Reviews
DSM Vendor Reviews

DSM Classifieds
DSM Parts Guides
DSM Photos
DSM Videos
DSM Timeslips
DSM Dyno Sheets
Shirts & Apparel
DSMtuners Decals

Advertising Info
Our Sponsors
Site Rules
Terms of Service
Privacy Policy
Site FAQ
About Us
Contact Us

© 2014 DSMtuners.com - All Rights Reserved

DSMtuners is not affiliated with Diamond Star Motors. The Mitsubishi Eclipse, Eagle Talon, Plymouth Laser, Mitsubishi Galant VR-4, and associated logos are trademarks of Diamond Star Motors, Mitsubishi Motors, and Chrysler Corporation. No, we do not hand out car sponsorships.

All times are GMT -7. The time now is 05:15 AM.


Vendor Tools vBulletin Plugins by Drive Thru Online, Inc.

Search Engine Optimization by vBSEO 3.6.0
